Type:Film multi-span greenhouse,polycarbonate multi-span greenhouse,Glass greenhouse
Frame structure:
(1)Hot dip galvanized steel Frame
(2)Main post:150150mm-100100mm
(3)Auxiliary post:12060mm-10050mm
(4)Thickness:1-2.5mm
(5)Truss:50502.5mm
(6)Zinc coating:average 210g/㎡
(7)Gutter:thickness 2.0-2.75mm,zinc coating 275g/㎡
Covering
(1)PO/PEP/HDPE plastic film single layer film covering/double layers films one layer thickness:120μm-200μm
(2)Polycarbonate:double/three layers
(3)Tempered glass
Single layer:4mm/5mm
Double layer 5+6+5 mm
Can be customized according to customer requirements
Film multi-span greenhouse Parameters:
(1)Wind load:0.55KN/㎡
(2)Snow load:0.45KN/㎡
(3)Maximum rainfall:140mm/h
(4)Planting bearing:0.2KN/㎡
Characteristics
1.Use accessories connect without welding
2.High quality hot dip galvanized steel frame,corrosion resistance,service life more than15 years
3.Covering materials include PO/PEP/HDPE woven plastic film,Polycarbonate,and Tempered Glasses
4.It can be matched with a variety of intelligent systems to achieve intelligent control 5.Provide a comfortable environment for plant growth and increase production
